D ON Surface-mounted ceiling spotlight

We use AI-generated or AI-enhanced product photos.

D ON Surface-mounted ceiling spotlight


  • Dimming technology
  • Housing colour - 002/black/RAL9005
    Bitte tragen Sie Ihre NCS/RAL Wunschfarbe hier ein, z.B. S 7005-R (NCS) oder RAL9876 (RAL). Ab einer Stückzahl von 6 Leuchten in gleicher Farbe entfällt der Aufschlag.
  • Light colour
Delivery time approx. 4 weeks
Item no. 30.6127.16A.002
Add to wishlist
Contact Us

D ON surface-mounted ceiling spotlight, 1 × SLED, power consumption 12.7 W, total luminous flux 980–1144 lm, rotatable and swivelling spotlight with adjustable glass lens and a beam angle of approx. 15–60°, Colour rendering/light colour: 2700 K/CRI98, 3000 K/CRI98, 4000 K/CRI98, control options: DALI-2, phase-cut dimmer (TRIAC), incl. driver, connection to 230 V AC/50 Hz, protection rating IP20, Single-lamp, finishes: black/RAL9005/002, white/RAL9010/003, graphite/RAL7015/006, snow white/RAL9016/060, aluminium grey/RAL9006/101, custom NCS/RAL colours available, see pictogram for dimensions, 5-year LED warranty

Technical data

Luminaire
Item number30.6127.*Installationsurface-mounted ceiling
Protection classIP20Weight0.7 kg
LED warranty5 years
ContentsIntegrated driver
Light
Light sourceSLEDPower consumption1 x max. 12.7 W
Luminous flux1 x max. 1046 lm · 1 x max. 1144 lm · 1 x max. 980 lmBeam angle15–60°
OpticsGlass lens, adjustable from 15° to 60°
Colour temperatures2700 K, CRI ≥ 98 (Sunlike) · 3000 K, CRI ≥ 98 (Sunlike) · 4000 K, CRI ≥ 98 (Sunlike)
LED module18 V, MacAdam Class 2Energy efficiency classF · G
Electrical
Power supply230 V, 50 HzControlDALI-2 · TRIAC
Finishes
Standard colours002 black RAL 9005 · 003 white RAL 9010 · 006 graphite RAL 7015 · 060 snow white RAL 9016 · 101 aluminium grey RAL 9006/9007
NCS standard coloursS 0500-N, S 1020-R20B, S 1020-R80B, S 2005-Y50R, S 3005-Y50R, S 3560-R80B, S 3560-Y80R, S 4020-B30G, S 4020-R80B, S 4020-Y60R, S 4550-Y50R, S 6020-G70Y
Colour of choiceNCS or RAL as specified
Versions
Item numberLight colourControlLuminous flux
30.6127.16A
30.6127.26A		2700 KTRIAC
DALI-2		1 x max. 980 lm
30.6127.16B
30.6127.26B		3000 KTRIAC
DALI-2		1 x max. 1,046 lm
30.6127.16C
30.6127.26C		4000 KTRIAC
DALI-2		1 x max. 1,144 lm
