Thiny Slim K surface-mounted wall light, 1 × SLED/LED, power consumption 6.3–31.5 W, total luminous flux 504–3565 lm, choice of diffusers: SOFT (opalescent diffuser), beam angle >90° at 30% power dissipation, PR (prismatic), beam angle 60° at 8% power dissipation, SPR (semi-prismatic), beam angle 60° at 10% power dissipation, PR/SPR achieve UGR <= 19 and comply with DIN EN 12464-1/-2, colour rendering/light colour: 2700 K/CRI98, 3000 K/CRI98, 4000 K/CRI95, control options: DALI-2, switchable, incl. driver, connection to 230 V AC/50 Hz, protection rating IP44, finishes: black/RAL9005/002, white/RAL9010/003, graphite/RAL7015/006, snow white/RAL9016/060, aluminium grey/RAL9006/101, custom NCS/RAL colours available, see pictogram for dimensions, 5-year LED warranty

Technical data

Luminaire
Item number22.2101.* · 22.2102.* · 22.2103.* · 22.2104.* · 22.2105.*InstallationWall mounting
Protection ratingIP44Weight0.6–1.4 kg
LED warranty5 years
ContentsIntegrated driver
Light
Light sourceLED · SLEDPower consumption6.3 W · 12.6 W · 18.9 W · 25.2 W · 31.5 W
Luminous flux504–3565 lmBeam angle60° · > 90°
OpticsSOFT: opal diffuser, > 90°, 30% power
loss PR: prismatic, 60°, 8% power loss, UGR ≤ 19
SPR: semi-prismatic, 60°, 10% power loss, UGR ≤ 19
Light colours2700 K, CRI ≥ 98 (Sunlike) · 3000 K, CRI ≥ 98 (Sunlike) · 4000 K, CRI ≥ 95
LED module18 V, MacAdam Class 3Energy efficiency classE · F
Electrical
Power supply230 V, 50 HzControlDALI-2 · non-dimmable
Finishes
Standard colours002 black RAL 9005 · 003 white RAL 9010 · 006 graphite RAL 7015 · 060 snow white RAL 9016 · 101 aluminium grey RAL 9006/9007
NCS standard coloursS 0500-N, S 1020-R20B, S 1020-R80B, S 2005-Y50R, S 3005-Y50R, S 3560-R80B, S 3560-Y80R, S 4020-B30G, S 4020-R80B, S 4020-Y60R, S 4550-Y50R, S 6020-G70Y
Colour of choiceNCS or RAL as specified
Dimensions
Length300–1500 mm
Versions
Item numberModelAppearanceLight colourPowerBeam angleControlLuminous flux
22.2101.J16
22.2101.T16		Thiny Slim 30 KSOFT2700 K6.3 W> 90°not dimmable
DALI-2		504 lm
22.2101.J17
22.2101.T17		Thiny Slim 30 KSOFT3000 K6.3 W> 90°not dimmable
DALI-2		504 lm
22.2101.J18
22.2101.T18		Thiny Slim 30 KSOFT4000 K6.3 W> 90°not dimmable
DALI-2		543 lm
22.2101.J26
22.2101.T26		Thiny Slim 30 KPR2700 K6.3 W60°not dimmable
DALI-2		663 lm
22.2101.J27
22.2101.T27		Thiny Slim 30 KPR3000 K6.3 W60°not dimmable
DALI-2		663 lm
22.2101.J28
22.2101.T28		Thiny Slim 30 KPR4000 K6.3 W60°not dimmable
DALI-2		713 lm
22.2101.J36
22.2101.T36		Thiny Slim 30 KSPR2700 K6.3 W60°non-dimmable
DALI-2		648 lm
22.2101.J37
22.2101.T37		Thiny Slim 30 KSPR3000 K6.3 W60°non-dimmable
DALI-2		648 lm
22.2101.J38
22.2101.T38		Thiny Slim 30 KSPR4000 K6.3 W60°non-dimmable
DALI-2		698 lm
22.2102.J16
22.2102.T16		Thiny Slim 60 KSOFT2700 K12.6 W> 90°not dimmable
DALI-2		1008 lm
22.2102.J17
22.2102.T17		Thiny Slim 60 KSOFT3000 K12.6 W> 90°not dimmable
DALI-2		1008 lm
22.2102.J18
22.2102.T18		Thiny Slim 60 KSOFT4000 K12.6 W> 90°not dimmable
DALI-2		1090 lm
22.2102.J26
22.2102.T26		Thiny Slim 60 KPR2700 K12.6 W60°not dimmable
DALI-2		1325 lm
22.2102.J27
22.2102.T27		Thiny Slim 60 KPR3000 K12.6 W60°not dimmable
DALI-2		1325 lm
22.2102.J28
22.2102.T28		Thiny Slim 60 KPR4000 K12.6 W60°not dimmable
DALI-2		1426 lm
22.2102.J36
22.2102.T36		Thiny Slim 60 KSPR2700 K12.6 W60°non-dimmable
DALI-2		1296 lm
22.2102.J37
22.2102.T37		Thiny Slim 60 KSPR3000 K12.6 W60°not dimmable
DALI-2		1296 lm
22.2102.J38
22.2102.T38		Thiny Slim 60 KSPR4000 K12.6 W60°not dimmable
DALI-2		1395 lm
22.2103.J16
22.2103.T16		Thiny Slim 90 KSOFT2700 K18.9 W> 90°not dimmable
DALI-2		1512 lm
22.2103.J17
22.2103.T17		Thiny Slim 90 KSOFT3000 K18.9 W> 90°not dimmable
DALI-2		1512 lm
22.2103.J18
22.2103.T18		Thiny Slim 90 KSOFT4000 K18.9 W> 90°not dimmable
DALI-2		1628 lm
22.2103.J26
22.2103.T26		Thiny Slim 90 KPR2700 K18.9 W60°non-dimmable
DALI-2		1988 lm
22.2103.J27
22.2103.T27		Thiny Slim 90 KPR3000 K18.9 W60°non-dimmable
DALI-2		1988 lm
22.2103.J28
22.2103.T28		Thiny Slim 90 KPR4000 K18.9 W60°non-dimmable
DALI-2		2139 lm
22.2103.J36
22.2103.T36		Thiny Slim 90 KSPR2700 K18.9 W60°non-dimmable
DALI-2		1944 lm
22.2103.J37
22.2103.T37		Thiny Slim 90 KSPR3000 K18.9 W60°non-dimmable
DALI-2		1944 lm
22.2103.J38
22.2103.T38		Thiny Slim 90 KSPR4,000 K18.9 W60°not dimmable
DALI-2		2093 lm
22.2104.J16
22.2104.T16		Thiny Slim KSOFT2700 K25.2 W> 90°not dimmable
DALI-2		2016 lm
22.2104.J17
22.2104.T17		Thiny Slim KSOFT3000 K25.2 W> 90°not dimmable
DALI-2		2016 lm
22.2104.J18
22.2104.T18		Thiny Slim KSOFT4000 K25.2 W> 90°not dimmable
DALI-2		2170 lm
22.2104.J26
22.2104.T26		Thiny Slim KPR2700 K25.2 W60°not dimmable
DALI-2		2650 lm
22.2104.J27
22.2104.T27		Thiny Slim KPR3,000 K25.2 W60°not dimmable
DALI-2		2,650 lm
22.2104.J28
22.2104.T28		Thiny Slim KPR4,000 K25.2 W60°non-dimmable
DALI-2		2852 lm
22.2104.J36
22.2104.T36		Thiny Slim KSPR2700 K25.2 W60°not dimmable
DALI-2		2592 lm
22.2104.J37
22.2104.T37		Thiny Slim KSPR3000 K25.2 W60°not dimmable
DALI-2		2592 lm
22.2104.J38
22.2104.T38		Thiny Slim KSPR4000 K25.2 W60°not dimmable
DALI-2		2790 lm
22.2105.J16
22.2105.T16		Thiny Slim KSOFT2700 K31.5 W> 90°non-dimmable
DALI-2		2520 lm
22.2105.J17
22.2105.T17		Thiny Slim KSOFT3000 K31.5 W> 90°not dimmable
DALI-2		2520 lm
22.2105.J18
22.2105.T18		Thiny Slim KSOFT4000 K31.5 W> 90°not dimmable
DALI-2		2,713 lm
22.2105.J26
22.2105.T26		Thiny Slim KPR2700 K31.5 W60°non-dimmable
DALI-2		3,312 lm
22.2105.J27
22.2105.T27		Thiny Slim KPR3000 K31.5 W60°non-dimmable
DALI-2		3312 lm
22.2105.J28
22.2105.T28		Thiny Slim KPR4000 K31.5 W60°non-dimmable
DALI-2		3,565 lm
22.2105.J36
22.2105.T36		Thiny Slim KSPR2700 K31.5 W60°not dimmable
DALI-2		3240 lm
22.2105.J37
22.2105.T37		Thiny Slim KSPR3000 K31.5 W60°not dimmable
DALI-2		3240 lm
22.2105.J38
22.2105.T38		Thiny Slim KSPR4000 K31.5 W60°not dimmable
DALI-2		3,488 lm
